TECHNICAL SPECIFICATIONS - CHASSIS
I
5
Collar bolt on front wheel spindle M24x1,5 40 Nm
Bolts on front brake caliper M8 Loctite 243 + 25 Nm
Collar bolts of front brake pads - FS models only M6 10 Nm
Bolts on brake disks M6 Loctite 243 + 10 Nm
Clamp bolts on top triple clamp M8 20 Nm
Clamp bolts on bottom triple clamp M8 15 Nm
Clamp nut on triple clamp M22x1 20 Nm
Clamp bolt on fork leg M8 10 Nm
Collar nut on rear axle passage M20x1,5 80 Nm
Hexagon nut on swing arm pivot M16x1,5 100 Nm
Collar bolt on handlebar clamp M8 20 Nm
AH bolt on handlebar mount M10 Loctite 243 + 40 Nm
Shock absorber top M12 60 Nm
Shock absorber bottom M10 40 Nm
Rear sprocket bolts M8 Loctite 243 + 35 Nm
Ball joint on push rod M6 Loctite 243 + 10 Nm
Engine cradle bolts M8 25 Nm
Side stand M8 20 Nm
Rim lock M8 6 Nm
Bolt on adjusting ring, spring preload, shock absorber M6 8 Nm
Spoke nipple M4,5 / M5 5 Nm
Other bolts on chassis M6 10 Nm
M8 25 Nm
M10 45 Nm
Other collar nuts on chassis M6 15 Nm
M8 30 Nm
M10 50 Nm
TIGHTENING TORQUES
