English - 27
2. SPECIAL MENU FUNCTIONS
• Current:
Shows the nominal regulated charging current to
and from the battery. A positive value indicates
that the battery is taking the charge while a
negative value indicates that the battery is not
taking the charge. Models 230 ACX and 260 ACX
display Current for battery A and B separately.
On Solar Hybrid current from both the solar panel
and from the battery is shown. If the mower finds
itself outside the charging station, a positive
battery current charges the battery from the solar
panel.
• Batt. Temp:
Shows the temperature of the battery. Models 230
ACX and 260 ACX display Batt. Temp for battery
A and B separately.
The loop system display mode presents:
• Loop signal value
Af = The strength of the A-signal measured via
the front loop sensor on the mower. The value
should lie between approximately 70 and 320 to
ensure good functionality. The closer to the loop
the mower is, the higher the value. When the
Automower
®
is directly over the loop the value is
0 and when the mower is outside of the loop the
value is negative.
When the Automower
®
is in the test position, see
page 39, the value for the F-signal should be
above 300 and for the N-signal the value should
be above 100.
To ensure the functionality of the guide wire, the
Guide signal value should be (-) 250 – 320 next
to the guide wire. The guide wire is named G1 for
220 AC and the guide wires are named G1 and
G2 for 230 ACX, Solar Hybrid and 260 ACX.
• Quality:
The loop signals can only be interpreted if the
Quality value is 100 %. When the value is 99 % or
lower, the loop system does not function correctly
and with that, the displayed values for the signals
will not be correct.
• Restarts:
Within 5 – 10 seconds after the function starts, the
restart value stabilises. When the value continues
to change this indicates that the system is affected
by interference or is defective.
Press YES to display further information in this display
mode. The Ar-signal is then shown instead, i.e. the
loop signal measured through the rear loop sensor.
The guideline values of approximately 70 – 320 also
apply for Ar. Press YES to exit this display mode.
Example: 220 AC
Example: 230 ACX, Solar Hybrid, 260 ACX
Af:
G1:
G2:
Quality:
Restarts:
F:
N:
250
-250
280
320
110
100%
0
Af:
G1:
Quality:
Restarts:
F:
N:
250
-250
320
110
100%
0
