26 - English
2. SPECIAL MENU FUNCTIONS
2.2 Quick check
When the main menu shows: Press and hold down the
number 0 for two seconds to access the Quick check
function.
Quick check is a display mode where you can quickly
see information about the software and operating
history, search times, battery, loop system and
sensors. Press YES to switch between the different
display modes. Press Arrow back to exit the quick
check function.
The display mode for software and operating history
shows:
• Program type: In this case 260 ACX GSM CD.
• Ver: The version of the mower program consists
of release (02.71), control card version (B:36)
and development version (U:00)
• Date: Date of issue.
• Chargings OK: The total number of chargings
where the battery was fully charged.
• Efficiency: A measure of how large a proportion of
the total operating time the Automower
®
spent
mowing the grass.
• Searching: A measure of how large a proportion of
the total operating time the Automower
®
spent
searching for the charging station.
Faults, number: The total number of faults that
occurred.
The display mode for mower's search times shows:
Search times: Lists the number of minutes it took the
mower to find the charging station from the time the
search began until the mower landed at the charging
station. The total time from the past 18 searches is
displayed.
The battery display mode presents:
• Voltage:
A value of about 21 V signifies a fully charged
battery and about 18 V signifies a discharged
battery.
• Charging:
Shows how much of the charge remains in the
battery.
When the battery is fully charged, the charge is
approximately 2200 mAh (220 AC, Solar Hybrid),
4400 mAh (230 ACX) or 6000 mAh (260 ACX).
When the charge has dropped to approximately
700 mAh (220 AC, Solar Hybrid) or 1200 mAh
(230 ACX, 260 ACX), the mower returns to the
charging station.
If the ambient temperature is high, the available
capacity in the battery drops. The mower adapts
itself to this and then returns to the charging
station earlier.
260 ACX GSM CD
Ver: 02.71 B:36 U:00
Date: Nov 26 2009
Chargings OK
Efficiency
Searching
Fault, number
15
98%
5%
4
Search times
1
: 0
2: 5
3: 2
4: 6
5: 10
6: 1
7: 3
8: 17
9: 3
10: 5
11: 4
12: 1
13: 6
14: 9
15: 2
16: 2
17: 0
18: 1
Example: 230 ACX
19.7 V
3400 mAh
3670 mA
30ºC
3810 mA
29ºC
Voltage:
Charging:
Current bat A:
Batt. Temp A:
Current bat B:
Batt. Temp B:
Example: Solar Hybrid
19.7 V
2000 mAh
515 mA
1750 mA
29ºC
Voltage:
Charging:
Solar current:
Current bat B:
Batt. Temp B:
