22 Digital Refractor CDR-9000
6
Near Point Rod Fixation Point: the place which affix the near point rod.
7
Horizontal Knob: Used to adjust horizontal balance using the (11) Level.
8
VD confirmation light: When patient’s forehead isn’t docking condition duri
ng measurement, informs to examiner by lamp.
1
Unit table arm connector: connect to Digital Refractor and Unit table arm.
2
Cable Connector Part: the parts which connect to interface cable.
3
Level: Used to verify that the refractor head is level.
4
Measuring Windows: patients look at the chart through these windows.
5
Face Shields: Patient’s face touches the shields during measurement. Clean t
hem before measurement.
6
Forehead Rest: Patient’s forehead should touch the rest during measuremen
