26 Digital Refractor CDR-9000
5.3.2. Detail Explanation: Rear side
1
Connector for the Junction Box: Port to connect the Operation Panel to the
Junction Box.
2
Connector for S/W upgrade: This port is used for downloading and upgradi
ng the Operation Panel firmware.
