Hyd-Mech S-23P User Manual

Pg 4.33 S23P
SECTION 4, ELECTRICAL SYSTEM
CONTROL PANEL & COMPONENTS
This machine has been built to the customers requirements, however, if any voltage changes are required, refer
to the information on the following pages and then consult Hyd-Mech service department before implementing any
changes. The following photos show the S-23P control panel layout.
The S-23P control panel layout.
The S-22P control panel.
Transformer
Control Fuses
Primary Fuses
Motor Contactors
Motor Overloads
Sequencer
