Hydac EDS 3000 User Manual

Mat No.: 669756 / Revised: 05.04.2018 E
18
Other data
Supply voltage
For use acc. to UL spec.
9 .. 35 V
DC
without analogue output
18 .. 35 V
DC
with analogue output
-limited energy – according to
9.3 UL 61010; Class 2;
UL 1310/1585; LPS UL 60950
Current consumption max. 2,455 A total
max. 35 mA with inactive switching output
max. 55 mA with inactive switching output
and analogue output
Display 4-digit, LED, 7-segment,
red, character height: 7 mm
Weight approx. 120 g
Note: Excess voltage, override protection and short circuit protection are provided.
FS (Full Scale) = refers to full measuring range
1) Environmental conditions according to 1.4.2 UL 61010-1; C22.2 No. 61010-1
2) With mounted mating connector in corresponding protection class
