Hydac EDS 3000 User Manual

Mat No.: 669756 / Revised: 05.04.2018 E
21
12.2 EDS 3000 WITH THIN FILM DMS SENSOR CELL; RELATIVE PRESSURE
STARTING AT 40 BAR
EDS 3 X X X - X - XXXX - V0X
Design (technology)
4 = Thin film DMS relative
Type of connection, mechanical
4 = G1/4 A ISO1179-2
9 = Port DIN 3852-G1/4
Type of connection, electrical
6 = Device plug M12x1, 4 pole (connector not supplied)
only possible on output models „1“, „2“ and „3“
8 = Device plug M12x1, 5 pole (connector not supplied)
only possible on output model “5” and
modification number “V02”
Output
1 = 1 Switch output
only in conjunction with electrical connection type “6”
2 = 2 Switch outputs
only in conjunction with electrical connection type “6”
3 = 1 Switching and 1 analogue output
only in conjunction with electrical connection type “6”
5 = 2 Switching outputs and 1 analogue output
only in conjunction with electrical connection type “8” and
modification number “V02”
Pressure range in bar
040;100; 250; 400; 600
1000 (only with mech. connection code „4“)
Modification number
V00 = Menu navigation in accordance with VDMA (standard sheet 24574-1)
V02 = Menu navigation in the style of VDMA (standard sheet 24574-1)
