Mat No.: 669756 / Revised: 05.04.2018 E
20
12 Ordering details
12.1 EDS 3000 WITH CERAMIC SENSOR CELL; ABSOLUTE AND RELATIVE
PRESSURE UP TO 16 BAR
EDS 3 X X X - X - XXXX - VXX - X 1
Design (technology)
1 = Ceramic absolute
3 = Ceramic relative
Type of connection, mechanical
4 = G1/4 A ISO1179-2
9 = Port DIN 3852-G1/4
Type of connection, electrical
6 = Device plug M12x1, 4 pole (connector not supplied)
only possible on output models „1“, „2“ and „3“
8 = Device plug M12x1, 5 pole (connector not supplied)
only possible on output model “5” and
modification number “V02”
Output
1 = 1 Switch output
only in conjunction with electrical connection type “6”
2 = 2 Switch outputs
only in conjunction with electrical connection type “6”
3 = 1 Switching and 1 analogue output
only in conjunction with electrical connection type “6”
5 = 2 Switching outputs and 1 analogue output
only in conjunction with electrical connection type “8” and
modification number “V02”
Pressure range in bar
Design 1 (ceramic absolute)
0001; 02.5
Design 3 (ceramic relative)
0001 (-1 .. 1 bar); 01.0; 02.5; 06.0; 0010; 0016
Modification number
V00 = Menu navigation in accordance with VDMA (standard sheet 24574-1)
V02 = Menu navigation in the style of VDMA (standard sheet 24574-1)
Seal material (parts in contact with the fluid)
F = FPM seal (e.g. for hydraulic oils)
E = EPDM seal (e.g. for water, coolant)
Material of connection (parts in contact with the fluid)
1 = Stainless steel
