Mat No.: 669756 / Revised: 05.04.2018 E
19
11.2 EDS 3000 WITH THIN FILM DMS SENSOR CELL;
RELATIVE PRESSURE STARTING AT 40 BAR
Input data
Measuring ranges
1)
bar 40 100 250 400 600 1000
Overload pressures bar 80 200 500 800 1000 1600
Burst pressure bar 200 500 1000 2000 2000 3000
Mechanical connection G1/4 A ISO1179-2
Port DIN 3852-G1/4
Tightening torque, recommended 20 Nm
Parts in contact with fluid Mech. connection: Stainless steel
Sensor cell: Thin film DMS; Seal: FPM
Output data
Switching outputs 1 or 2 PNP transistor outputs
Switching current: max. 1.2 A per output
Switching cycles: > 100 million
Analogue output, permitted load resistance
Selectable: 0 .. 10 V; Load resist. min. 1 kΩ
4 .. 20 mA; Load resist. max. 500 Ω
Accuracy acc. to DIN 16086
Terminal based
≤ ± 0.5 % FS typ.
≤ ± 1 % FS max.
Temperature compensation, zero point ≤ ± 0.015 % FS / °C typ.
≤ ± 0.025 % FS / °C max.
Temperature compensation, span ≤ ± 0.015 % FS / °C typ.
≤ ± 0.025 % FS / °C max.
Repeatability ≤ ± 0.25 % FS max.
Reaction time < 10 ms
Long-term drift ≤ ± 0.3 % FS typ./ year
Environmental conditions
Compensated temperature range -10 .. + 70 °C
Operating temperature range -25 .. + 80 °C (-25 .. 60 °C acc.to. UL-Spez.)
Storage temperature range -40 .. + 80 °C
Fluid temperature range -25 .. + 80 °C
mark
EN 61000-6-1, 2, 3, 4
-mark
2)
Certificate No.: E318391
Vibration resistance acc. to
DIN EN 60068-2-6 at 10 to 500 Hz
≤ 10 g
Shock resistance acc. to
DIN EN 60068-2-29 (11ms)
≤ 50 g
Protection class acc. to DIN EN 60529
3)
IP 67
Other data
Supply voltage
For use acc. to UL spec.
9 .. 35 V
DC
without analogue output
18 .. 35 V
DC
with analogue output
-limited energy – acc. to 9.3 UL 61010; Class 2;
UL 1310/1585; LPS UL 60950
Current consumption max. 2,455 A total
max. 35 mA with inactive switching output
max. 55 mA with inactive switching output
and analogue output
Display 4-digit, LED, 7-segment,
red, character height: 7 mm
Weight: approx. 120 g
Note: Excess voltage, override protection and short circuit protection are provided.
FS (Full Scale) = refers to full measuring range
1) 1000 bar only with mechanical connection G1/4 A ISO1179-2
2) Environmental conditions according to 1.4.2 UL 61010-1; C22.2 No. 61010-1
3) With mounted mating connector in corresponding protection class
