Mat No.: 669756 / Revised: 05.04.2018 E
25
ZBM 3200
Spray protection
(Material: Elastollan S60 A15 SPF 000)
Material-No.: 3201919
14 Device dimensions
Display adjustable 270°
Housing adjustable 340°
FPM- / EPDM seal
Diamete
r
connector M12x1
4-
p
ole / 5
p
ole
6he
x
-SW27
G1/4 A ISO 1179-2
