Hydac EDS 3000 User Manual

Mat No.: 669756 / Revised: 05.04.2018 E
23
ZBE 08 (5 pole)
Female connector M12x1,
right-angle
Cable diameter:
2,5 .. 6,5 mm
Part No.: 6006786
ZBE 08-02 (5 pole)
Female connector M12x1,
right-angle with 2 m cable
Part No.: 6006792
ZBE 08-05 (5 pole),
Female connector M12x1,
right-angle with 5 m cable
Part No.: 6006791
Colour code: Pin 1: brown
Pin 2: white
Pin 3: blue
Pin 4: black
Pin 5: grey
ZBE 08S-02 (5 pole),
Female connector M12x1,
right-angle, with 2 m
cable, shielded
Part No.: 6019455
ZBE 08S-05 (5 pole),
Female connector M12x1,
right-angle, with 5 m
cable, shielded
Part No.: 6019456
ZBE 08S-10 (5 pole),
Female connector M12x1,
right-angle, with 10 m
cable, shielded
Part No.: 6023102
Colour code: Pin 1: brown
Pin 2: white
Pin 3: blue
Pin 4: black
Pin 5: grey
