15.6 Accessories
W A R N I N G
Personal injury hazard. Use of non-approved parts may cause personal injury, damage to the
instrument or equipment malfunction. The replacement parts in this section are approved by the
manufacturer.
Note: Product and Article numbers may vary for some selling regions. Contact the appropriate distributor or refer to
the company website for contact information.
Description Quantity Item no.
Rhodamine Calibration Dye Solution, 21.33 ± 2.5 w/w% 236 mL (8 oz) 007273
Solid Secondary Standard 1 007726
Section 16 Temperature sensor (004165HY)
16.1 Specifications
Specifications are subject to change without notice.
Specification Details
Range –5 to 50 °C (23 to 122 °F), non-freezing
Accuracy ±0.10 °C (±0.18 °F)
Resolution 0.01 °C (0.02 °F)
Maximum depth 200 m (656 ft)
16.2 Product overview
The temperature sensor (004165HY) is shown in Figure 20.
Figure 20 Temperature sensor (004165HY)
16.3 Sensor guidelines
Keep deposits off the sensor for best measurements. Examine the sensor to make sure that there
are no contaminants. Keep the substances shown in Table 13 away from the sensor.
Table 13 Contaminants
Substance Damage
Oil, sediment or biofilms Contaminates the sensor. If the sensor is contaminated, clean the sensor.
16.4 Maintenance
16.4.1 Clean the sensor
N O T I C E
To prevent damage to some sensors, do not use solvents that dissolve plastic to clean the sensors.
Note: It may be necessary to clean the sensor more frequently if the sensor is used in environments with sediment
(i.e., silt), mineral precipitate, biofilms, barnacles or pollutants such as oil.
English
39
