APPENDIX C – BEVEL CUTTING
c-14 HPR260 Manual Gas Instruction Manual
1. Leads for use with the standard quick-disconnect (220163)
All leads have standard fittings that are identical to the hoses listed in the Installation section in this manual. The only
difference is that the gas leads have been extended to 2.5 m (8.17 ft).
2. Leads for use with the bevel quick-disconnect/short torch-sleeve assembly (220573)
All of the gas leads have push-to-connect fittings and can only be used with the 220573 assembly. The 2 hoses to the
off-valve have adapters that change the push-to-connect fitting to a screw-on fitting.
*Use of these lead assemblies will result in reduced consumable life.
4
Part number Overall length Gas lead length
228075 1.83 m (6 ft) 1.83 m (6 ft)
228076 3.05 m (10 ft) 1.83 m (6 ft)
228079 4.5 m (15 ft) 1.83 m (6 ft)
228081 7.5 m (25 ft) 1.83 m (6 ft)
228083 10 m (35 ft) 1.83 m (6 ft)
228086 15 m (50 ft) 1.83 m (6 ft)
228088 20 m (65 ft) 1.83 m (6 ft)
228077* 3.05 m (10 ft) 2.5 m (8.17 ft)
228061* 4.5 m (15 ft) 2.5 m (8.17 ft)
228062* 7.5 m (25 ft) 2.5 m (8.17 ft)
228084* 10 m (35 ft) 2.5 m (8.17 ft)
228063* 15 m (50 ft) 2.5 m (8.17 ft)
228089* 20 m (65 ft) 2.5 m (8.17 ft)
Part number Overall length Gas lead length
128986 1.83 m (6 ft) 1.83 m (6 ft)
128935 3.05 m (10 ft) 1.83 m (6 ft)
128934 4.5 m (15 ft) 1.83 m (6 ft)
128784 7.5 m (25 ft) 1.83 m (6 ft)
128987 10 m (35 ft) 1.83 m (6 ft)
128785 15 m (50 ft) 1.83 m (6 ft)
128988 20 m (65 ft) 1.83 m (6 ft)
228040* 4.5 m (15 ft) 2.5 m (8.17 ft)
228043* 7.5 m (25 ft) 2.5 m (8.17 ft)
228065* 10 m (35 ft) 2.5 m (8.17 ft)
228045* 15 m (50 ft) 2.5 m (8.17 ft)
228066* 20 m (65 ft) 2.5 m (8.17 ft)
