HyPrecision 50S/60S/75S Operator Manual 808690 53
4 – Operation
Operation
The indicator bars show the stroke rate for the intensifier. A green bar shows that the intensifier stroke rate is
within the allowable range. A yellow bar shows that the stroke rate is at the limit of the allowable range. A red bar
shows that the intensifier is overstroking. For troubleshooting, refer to the
Stroking problems section, which
begins on page 159.
Touch the status indicator to open the intensifier settings screen.
