64 HyPrecision 50S/60S/75S Operator Manual 808690
4 – Operation
Operation
Input/output status
This screen shows all inputs and outputs on the controller. Green shows enabled status. Red shows disabled
status. These can be helpful for troubleshooting.
I1 Hydraulic fluid level
l2 Hydraulic fluid temperature is higher than 55°C
I3 Hydraulic fluid temperature is higher than 65°C
I4 Hydraulic fluid temperature is higher than 45°C
l5 Supply water pressure is 40 psi or higher
l6 Front intensifier left proximity switch
l7 Front intensifier right proximity switch
l8 Rear intensifier left proximity switch
l9 Not used
l10 Not used
l11 Not used
l12 Not used
l13 Rear intensifier right proximity switch
l14 Not used
l15 Control on
I16 Remote mode active
l17 Remote pump on
l18 Remote pump off
l19 Remote cooling on
l20 Remote pierce-pressure enable
l21 Primary motor fault
l22 Primary motor run
l23 Boost pump run
I24 Air cooler fan run
