Hypertherm Powermax 125 Field Service Bulletin

Torch Alignment Guide for Bevel Cutting
4 811280 Field Service Bulletin Powermax125 / MAXPRO200
Figure 1 – Torch alignment guide
1
2
3
4
5
1 Metric units (cm/mm)
2 Torch clearance gauge for Air/Air processes
3 Set screw
4 English units (inches)
5 Torch clearance gauge for O
2
/Air processes
(MAXPRO200 only)
