SETUP
1
powermax1250 Operator Manual 3-17
+
–
+
–
Driving an industrial isolated input module with an external power source
Notes:
• Customer-supplied
isolated input module.
• Customer-supplied
24 VDC power source.
• Pins 5 and 6 are used only on
systems that include the
PowermaxEdge cable with
voltage divider.
Start
Signal
Shield
13
12
14
3
4
6
5
V-div +
V-div -
24 VDC
Isolated input
module
J19
GND 24VDC BLK YEL RED WHT
XFER START
J16 J15
