Service Manual
Rear Panel
No. Part Name No. Part Name
â—‹
1
RF Antenna Connector
â—‹
2
Power Inlet
â—‹
3
Accessory Jack
â—‹
4
GPS Antenna Connector
Note: The GPS Antenna Connector is only available for MD78XG.
6
