Chapter 9 Appendix
315
Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction
Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
5
300
(at 50 to 650st)
250
(at to 700st)
220
(at to 750st)
190
(at to 800st)
170
(at to 850st)
160
(at to 900st)
140
(at to 950st)
130
(at to 1000st)
120
(at to 1050st)
110
(at to 1100st)
0.3 – – –
10
Horizontal/
Vertical
600
(at 50 to 650st)
500
(at to 700st)
440
(at to 750st)
390
(at to 800st)
350
(at to 850st)
320
(at to 900st)
290
(at to 950st)
260
(at to 1000st)
240
(at to 1050st)
220
(at to 1100st)
0.5 – – –
RCS3CR
(Slider Type)
SA8
(Note)
100 16384
20
Horizontal/
Vertical
1200
(at 50 to 650st)
1010
(at to 700st)
890
(at to 750st)
790
(at to 800st)
710
(at to 850st)
640
(at to 900st)
580
(at to 950st)
530
(at to 1000st)
480
(at to 1050st)
440
(at to 1100st)
0.7 – – –
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the
setting for the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
