IAI MSCON - Page 335

Chapter 9 Appendix
327
Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction
Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
20 Horizontal
1200
(at800 to 1100st)
1100
(at to 1200st)
1000
(at to 1300st)
950
(at to 1400st)
800
(at to 1500st)
700
(at to 1600st)
600
(at to 1700st)
550
(at to 1800st)
500
(at to 1900st)
450
(at to 2000st)
0.4 – – –
ISB
ISPB
(Slider Type)
MXMX 200 16384
30 Horizontal
1800
(at800 to 1100st)
1650
(at to 1200st)
1500
(at to 1300st)
1425
(at to 1400st)
1200
(at to 1500st)
1050
(at to 1600st)
900
(at to 1700st)
825
(at to 1800st)
750
(at to 1900st)
675
(at to 2000st)
0.4 – – –
ME0306-2A
