Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction
Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
0.7
10
Horizontal
Vertical
600
(at 120 to 770st)
460
(at to 870st)
380
(at to 970st)
320
(at to 1070st)
270
(at to 1170st)
220
(at to 1270st)
0.6
– – –
1.2
20
Horizontal
Vertical
1200
(at 120 to 770st)
920
(at to 870st)
765
(at to 970st)
645
(at to 1070st)
550
(at to 1170st)
440
(at to 1270st)
1.0
– – –
ISB
ISPB
(Slider Type)
LXL
(Note)
200 16384
40
Horizontal/
Vertical
2400
(at 120 to 770st)
1840
(at to 870st)
1530
(at to 970st)
1290
(at to 1070st)
1100
(at to 1170st)
880
(at to 1270st)
1.2 – – –
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the
setting for the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
