Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction
Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
20 Horizontal
1200
(at 1000 to
1200st)
1150
(at to 1300st)
1000
(at to 1400st)
950
(at to 1500st)
830
(at to 1600st)
740
(at to 1700st)
650
(at to 1800st)
590
(at to 1900st)
540
(at to 2000st)
490
(at to 2100st)
440
(at to 2200st)
410
(at to 2300st)
370
(at to 2400st)
340
(at to 2500st)
0.4
－ － －
ISDBCR
ISPDBCR
(Slider Type)
LX 200 16384
40 Horizontal
1800
(at 1000 to
1500st)
1660
(at to 1600st)
1480
(at to 1700st)
1300
(at to 1800st)
1180
(at to 1900st)
1080
(at to 2000st)
980
(at to 2100st)
880
(at to 2200st)
820
(at to 2300st)
740
(at to 2400st)
680
(at to 2500st)
0.4 － － －
