3.4 Fieldbus Type Address Map
78
Note1: For CC-Link, n and n+1 are for input and output bit addresses, and n+8 is for the top
address of data register.
Note2: This is the domain occupied unconditionally. Therefore, this domain cannot be used for
any other purpose.
◎ In the case of CC-Link
Station Type: Ver.2 Remote device station
Extended Cyclic Setting/Occupied Station Number Setting:
Register the information of the occupations displayed on Gateway Parameter Setting Tool to
the master unit. Connection cannot be established if information other than occupation is set.
[Refer to 3.2 Initial Setting.]
Caution: ● Remote I/O Mode cannot be used together with other modes.
● Only Positioner 3 Mode and Remote I/O Mode are available to be selected in
CompoNet. (CompoNet occupies 32 bytes no matter of the number of axes.)
