Chapter 10
Appendix
POWER CON
PCON-CB/LC
242
[3]
Examples of Safety Circuits
1) In case of category 1
TB-02D, TB-01D(R), CON-PGAS
(or Dummy plug : DP-4S)
Connection Cable CB-CON-LB□□□
Controller
● PCON
Enable SW
SW
Reset
SW
Emergency
Stop
24V
24V
0V
0V
RCB-LB-TGS
Solenoid Contactor
Motor
Power
Supply
ENBOUT
ENBIN
ENB2+
ENB2-
ENB1+
ENB1-
EMGOUT
EMGIN
EMG2+
EMG2-
EMG1+
EMG1-
12
11
10
9
8
7
6
5
4
3
2
1
MPI
MPO
EMG-
S2
S1
24V
255
257
