IAI PCON-CFB series User Manual

Chapter 2 Wiring
POWER CON
PCON-CB/LC
37
Chapter 2 Wiring
2.1 Positioner Mode (PIO Control)
2.1.1 Wiring Diagram (Connection of Devices)
Caution : Make sure to turn the power to the controller OFF when inserting or removing
the connector that connects the PC software or touch panel teaching to the
controller.
Inserting or removing the connector while the power is turned ON causes a
controller failure.
Touch Panel Teaching
(to be purchased separately)
PC Software
(to be purchased separately)
A
ctuato
r
Host System
(PLC, etc.…Please prepare separately)
Power Source I/O Control
(24V DC
…Please prepare separately)
Emergency Stop Circuit
Control/Driving Power Supply
(24V DC
…Please prepare separately)
