IAI PCON-CFB series User Manual

Chapter 1 Specications Check
POWER CON
PCON-CB/LC
31
1.4 I/O Specifications
1.4.1 PIO Input and Output Interface
Input Section Output Section
Input Voltage
24V DC ±10%
Load Voltage 24V DC
Input Current 5mA 1circuit
Peak Load
Electric Current
50mA 1circuit
Specification
ON/OFF
Voltage
ON Voltage MIN. 18V DC
OFF Voltage MAX. 6V DC
Leakage
Current
MAX. 2mA/1point
NPN
680
5.6K
P24
External
Power Supply
24V DC
Input
Terminal
Internal Power Source
PCON
15
P24
N
Load
External
Power Supply
24V DC
Output
Terminal
Internal Power Source
PCON
PNP
680
5.6K
N
External
Power Supply
24V DC
Input
Terminal
Internal Power Source
PCON
15
P24
N
Load
External
Power Supply
24V DC
Output
Terminal
Internal Power Source
PCON
I/O Cable Refer to 2.1.3 [4] PIO Circuit
Insulated Insulation with Photocoupler
NPN Specification PNP Specification
Pin No.
Pin No.
Load
Load

IAI PCON-CFB series Specifications

General

Brand	IAI
Model	PCON-CFB series
Category	Controller
Language	English
