POWER CON
PCON-CB/LC
17
(5) Gripper T
ype
(3-Finger Gripper)
Note
Finger attachment is not in
cluded in the actuator package. Please p
repare separately
.
(6) Rotary T
ype
(330
°
Rotatio
n S
pecification)
(Multiple Rotation S
pecification)
For Multiple Rotation
T
ype with the origin reversed type, the directions of
+
and
−
are the oth
er way
around.
０
330
°
－
＋
+
+
+
Finger Attachment
(Note)
30
32
