IAI PCON-CFB series User Manual

Chapter 1 Specications Check
POWER CON
PCON-CB/LC
23
Item PCON-CB/CGB PCON-CFB/CGFB
LED Display
(mounted on Front Panel)
SV (GN)/ALM (RD) : Servo ON/Alarm generated
STS0 to 3 : Status display
RDY (GN)/ALM (RD) : Absolute function in normal / absolute function error
(for the simple absolute type)
1, 0 (GN) (RD) : Absolute function status display
(for the simple absolute type)
Electromagnetic Brake Compulsory
Release Switch (mounted on Front
Panel)
Switching NOM (standard)/BK RLS (compulsory release)
Insulation Resistance
500V DC 10MΩ or more
Protection Function against Electric
Shock
Class I basic insulation
Main Body
(PIO Type)
Screw fixed type : 250g or less
DIN rail fixed type : 285g or less
Screw fixed type : 270g or less
DIN rail fixed type : 305g or less
Main Body
(Field Network Type)
Screw fixed type : 280g or less
DIN rail fixed type : 315g or less
Screw fixed type : 300g or less
DIN rail fixed type : 335g or less
Mass
(Note 3)
Simple Absolute Type Battery (AB-7) : 190g or less
Absolute battery case (SEP-ABU) : 140g
Cooling Method Natural air-cooling Forced air-cooling
External dimensions
Screw fixed type :
35W×178.5H×69.6D
DIN rail fixed type : 35W×185H×78.1D
Screw fixed type : 35W×190H×69.6D
DIN rail fixed type : 35W×196.5H×78.1D
Surrounding Air Temperature
0 to 40°C
Surrounding Humidity 85% RH or less (non-condensing)
Surrounding Environment [Refer to Installation Environment]
Surrounding Storage
Temperature
-20 to 70°C (Excluding battery)
Usage Altitude 1000m or lower above sea level
Protection Class IP20
Environment
Vibration Resistance Frequency 10 to 57Hz / Swing width : 0.075mm
Frequency 57 to 150Hz / Acceleration : 9.8m/s
2
XYZ Each direction Sweep time : 10 min. Number of sweep: 10 times
Note 1 Value increases in 0.3A for Fieldbus Type.
Note 2 In-rush current will flow for approximately 1 to 5msec after the power is turned on (at 40°C).
The value of inrush current differs depending on the impedance of the power supply line.
Note 3 Add the mass of the battery and battery case for Simple Absolute Type.
