IAI pcon User Manual

1. Overview
8
1.1 EtherNet/IP Specifications
Item Specification
Communication standards IEC61158 (IEEE802.3)
Baud rate
10BASE-T/100 BASE-T
(Auto negotiation setting is recommended.)
Communication cable length
Refer to EtherNet/IP specifications
(The distance between the hub and each node must be within 100 m
Note 1
)
Number of connections Varies depending on the master unit.
Applicable node address 0.0.0.0 to 255.255.255.255
Communications cable
Category 5e or above
(Aluminum tape and braided double-shielded cable are recommended.)
Connector RJ45 connector (1 per connector)
(Note 1) For details, refer to the installation manual for ODVA, etc.

IAI pcon Specifications

General

Number of Axes	1-4
Manufacturer	IAI
Category	Controller
Power Supply	24 VDC
Programming	PC software
Communication Interface	RS-232, RS-485
Dimensions	Varies by model
Communication Protocols	RS-232
