2.6 Communicating with the Master Station
2.6.1 Operation Modes and Corresponding PLC I/O Areas
The addresses allocated for each operation mode are described as follows.
PLC output ACON/PCON input (* “n” indicates the first output address of each axis.)
DI on the ACON or PCON side and input data register
Remote I/O mode
Position/simplified
direct value mode
Half direct value
mode
Full direct value
mode
Remote I/O mode 2
PLC output
area (bytes)
Number of
occupied bytes: 2
Number of
occupied bytes: 8
Number of
occupied bytes: 16
Number of
occupied bytes: 32
Number of
occupied bytes: 12
n, n+1 Port No.0 to 15 Port No.0 to 15
n+2, n+3
Target position Target position Target position
n+4, n+5
Specified position
number
n+6, n+7 Control signal
Positioning band Positioning band
n+8, n+9 Speed
n+10, n+11
Acceleration/
deceleration
Speed setup
Occupied area
n+12, n+13
Pressing
current-limiting
value
n+14, n+15 Control signal
Zone boundary+
n+16, n+17
n+18, n+19
Zone boundary-
n+20, n+21 Acceleration
n+22, n+23 Deceleration
n+24, n+25
Pressing
current-limiting
value
ACON
Occupied
area
n+26, n+27
PCON
Load
current
threshold
n+28, n+29 Control signal 1
n+30, n+31 Control signal 2
(Note) The Occupied area shows the domain to be occupied with the operation mode setting.
