3. SCON-CA
167
(31) Standstill mode selection (ASC0, ASC1) PLC output signals
Select the stop mode to be applied while the actuator is standing by to move to the next position after
completing a positioning.
If the actuator remains standstill for a long time, the servo is turned off automatically to lower the power
consumption.
For details, refer to the operation manual for your controller.
ASO1 ASO0 Function Remarks
OFF OFF Disabled Factory setting
OFF ON
Automatic servo OFF method
Parameter No. 36 is enabled for T in the figure below.
ON OFF
Automatic servo OFF method
Parameter No. 37 is enabled for T in the figure below.
ON ON
Automatic servo OFF method
Parameter No. 38 is enabled for T in the figure below.
Movement command
Servo ON
status
Auto servo OFF mode
(A green LED blinks.)
Delay time until the servo turns off after
completion of positioning (sec)
Target position
Servo status
Actuator movement
