4. Appendix
192
[5] Double-click “Anybus-CC EtherNet/IP” in the main window and set the controller device parameters as
follows:
Item Set value
0001 Output Size 2
0002 Input Size 2
0003 RPI Range 10000 (default value)
[6] Double-click “CJ2M EIP21” in the main window to open the PLC’s “Edit Device Parameters” dialog box, and
select “Anybus-CC EtherNet/IP” under “List of Unregistered Devices” and register the device.
