IAME MINI SWIFT 60CC - USA User Manual

1
MAN-85 – USA
ENGINE CHARACTERISTICS – OPERATIONAL LIMITS
The characteristics of the engine are the following :
 Cycle: OTTO / 2 stroke
 Original cubic capacity: 59.00 cc
 Original bore 41.80
 Max. theoretical bore: 42.10 mm
 Stroke : 43.00 mm
 Lubrication : fuel-oil mix 6%
 Induction: inlet in 3rd port (Piston Port)
 Carburetor: Diaphragm type, Tillotson HW-31A (Ø17mm)
 Cooling : Free air
 Ignition : Analogic / 2 poles, with internal rotor
 Electric starter: 12V / 0.15 Kw
 Clutch : Automatic, dry centrifugal
Operational limits:
 Max.RPM / 1’ : 14.500 RPM
ATTENTION:
Never exceed the above limits, no obligation of IAME exists in case the above
limits are exceeded.
1- CONTENTS OF PACKING
Each engine is supplied with the accessories under shown:
EXHAUST
Quantity
 Exhaust silencer spring
2
 Exhaust manifold
1
 Exhaust muffler
1
INDUCTION
 Tillotson carburettor
1
 Intake silencer
1
 Intake silencer support
1
ELECTRIC PLANT
 Battery support
1
 Battery fixing strap
1
 Battery fixing clamps
2
 Electrical harness
1
 Push buttons support bracket
1
 Starter relay
1
 NGK BR 9 EG spark plug
1
 Spark plug cap
1
 Fixing clamps
8
MISCELLANEOUS
 Clutch cover with coil
1
