IAME Parilla Norswift 60cc User Manual

2 MAN-071
ENGINE CHARACTERISTICS
The Characteristic of the engine are the following:
 Cycle:
 Original cubic capacity
 Original bore:
 Max. Theorical bore:
 Stroke:
 Lubrification :
 Inductiion:
 Carburettor:
 Cooling:
 Ignition:
 Clutch:
 Starting:
OTTO / 2 Stroke Single Cylinder
59.42 cm³ (60.00 cm³ max)
41.80 mm
42.00 mm
43.30 mm
Fuel-oil mix / oil 3%
Piston Port
Diaphragm type, Tillotson HL series
Air
Analogical
Automatic, 3-mass Centrifugal Dry
Pull Start
OPERATIONAL LIMITS:
Max. RPM / 1’: 12.500 RPM (Without limiter)
ATTENTION:
Never exceed the above limits, no obligation of IAME exists in case the above limits are
exceeded.
1- CONTENTS OF PACKAGING
Each engine NORSWIFT is supplied with the accessories shown below:
EXHAUST GROUP
Quantity
 Exhaust Muffler Springs
2
 Exhaust Manifold No restricted / OR with restrictor Ø12.5mm
1
 Exhaust Muffler
1
INLET GROUP
 Tillotson HL series Carburettor (Ø19.8mm / Ø16mm restricted)
1
 Intake Silencer with Fixing clamp
1
 Intake Silencer Support
1
 Gas cable bracket with accessories
1
 Thermal Spacer + Gaskets
2+3
 Fuel Pipe
1
ELECTRIC GROUP
 H.T. Coil (Assembled on to the engine)
1
 Kill Switch + Switch Bracket (Assembled on to the engine)
1+1
 Connective Cable H.T. Coil to Switch
1
 Sparkplug NGK BR 9 EG
1
MISCELLANEUOS
 Clutch Cover
1
