Technical specifications
IAR Debug Probes User Guide
I-jet®, I-jet Trace, and I-scope™
11 TgtPwr Output This pin can be used for supplying 5 V power to the
target hardware from I-jet.
12 Not
used
TRACECLK Input Input trace clock.
13 TgtPwr Output This pin can be used for supplying 5 V power to the
target hardware from I-jet.
14 Not
used
TRACEDATA[0]
/
SWO2
Input Input Trace data pin 0. This pin can be used as
secondary SWO.
15 This pin is a GND pin connected to GND in I-jet. It
should also be connected to GND in the target
system.
16 Not
used
TRACEDATA[1]
/
nTRST
Input Input Trace data pin 1. This pin can be used as
nTRST.
17 This pin is a GND pin connected to GND in I-jet. It
should also be connected to GND in the target
system.
18 Not
used
TRACEDATA[2] Input Input Trace data pin 2.
19 This pin is a GND pin connected to GND in I-jet. It
should also be connected to GND in the target
system.
20 Not
used
TRACEDATA[3] Input Input Trace data pin 3.
Pin Signal Type Description
Table 3: MIPI-20 pin definitions (Continued)
