89
1
11
10
20
Figure 2-1 Power Supply Connectors (Bottom View)
Figure 2-2 Hard Drive or CD-ROM End of Power Cable
Figure 2-3 3.5-In. Diskette Drive End of Power Cable
006 - ARE THE VOLTAGES CORRECT AND DOES THE
FAN RUN? (YES, READ AHEAD. NO, GO TO
STEP 009)
q
The power supply is working normally.
q
If you suspect the on/off switch cable assembly, see
Step 003.
q
If the fan continues to run when all connectors are
plugged back in, go to “Undetermined Problems” on
To Next Page
