120
Adapter Cards
Installing Adapter Cards
q
Remove the screw that secures the adapter card
retainer and slot cover. Then remove the card retainer
and slot cover.
q
Align and insert the adapter card into the adapter card
connector.
q
Secure the card with the screw that you removed in the
first step.
q
Reinstall all hardware (except for the slot cover, which
cannot be reinstalled) and screws that you removed prior
to the installation of the adapter card.
Removing Adapter Cards
Follow these steps to remove an adapter card:
q
Position the system unit so that the card is accessible to
you.
q
If the adapter card has cables, disconnect them. Be sure
to take note of where the cables are connected. You will
have to reconnect these cables when you reinstall the
card.
q
Remove the adapter card screw.
q
Firmly hold the adapter card and carefully pull it from the
card connector.
q
If you are not reinstalling the card, reinstall all other
hardware and screws that were removed prior to the
removal of the adapter card.
