Power Supply
001 - START
q
Power off the system unit.
q
Check the power cord for continuity. Replace if
necessary.
q
Check for the correct line voltage from the power outlet,
and verify that the voltage selector switch is set to the
correct voltage.
q
Power on the system unit.
002 - DOES THE POWER SUPPLY FAN RUN? (YES, GO
TO STEP 003. NO, GO TO STEP 004)
003 - DOES THE SYSTEM FAIL TO SHUT OFF WHEN
THE ON/OFF SWITCH IS PRESSED? (YES, READ
AHEAD. NO, GO TO STEP 005)
q
You might have a damaged on/off switch cable
assembly.
q
Disconnect the on/off switch cable assembly connector
from the power supply connector and take an ohm
reading.
q
Go to step 007.
004 -
q
Disconnect the power cord from the back of the system
unit.
q
Disconnect all power and switch cable connectors from
the system board and the power supply.
q
Disconnect the power connectors to all drives.
q
Connect the power connector to system board as a
power load for driving up power supply.
q
Reconnect the power cord.
005 - DOES THE POWER SUPPLY FAN RUN? (YES,
READ AHEAD. NO, GO TO STEP 009)
q
With the system powered on and the power supply fan
running, check the voltages of the power supply
connectors for the system board and all drive
connectors, as shown in the following figures.
