IBM 2193 Hardware Maintenance Manual

175
Jumper and ConnectorSettings of the System Board of the
Machine Type 2194 and 6345
$
I/O Ports Connector
USB USB port.
IDE1 For Primary IDE port.
IDE2 For Secondary IDE port.
PS/2
For PS/2 Mouse & Keyboard
port.
FLOPPY For Floppy port.
COMA
For Serial port1 (COM
A){Support Modem Ring On}.
LPT For LPT port.
VGA For VGA Port.
ATX Power For ATX Power Connector.
GAME & Audio
For Game & MIC LINE-IN,
LINE-OUT,TEL Port ,CD-IN,
AUX-IN, SPDIF OUT
(Optional)
$
Socket 370
For Socket 370 Processor installed
$
IR : INFRARED Connector (IR / CIR)
Pin No. Function
1VCC
2NC
3 IRRX
4GND
5IRTX
6NC
7 CIRRX
8VCC
9NC
10 NC
$
CPU FAN : CPU cooling FAN Power
Connector
Pin No. Function
1 GND.
