IBM 2193 Hardware Maintenance Manual

177
2,3 GND
4 CD_R
$
JP11:AUX_IN
Pin No. Function
1AUX_L
2,3 GND
4AUX_R
$
J14:Wake on LAN
Pin No. Function
1 +5VSB
2GND
3 Signal
$
JP3:TEL –The connector for Modem with
internal voice connector.
Pin No. Function
1 Phone-in
2,3 GND
4 Mono-out
$
JP1:STR Enable
Pin No. Function
Close STR Enable
Open STR Disable (Default)
$
JP14: Case Open
Pin No. Function
1 Signal
2GND
$
JP13 : Safe Mode/Recovery/Normal
Pin No. Function
1-2 close Normal (Default)
2-3 close Safe Mode
1-2-3open Recovery
$
JP16: Top Block Lock
Pin No. Function
Open Top Block Lock
Close Top Block Unlock (Default)
