v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v See Chapter 4, “Parts listing, Types 7871 and 1949,” on page 41 to determine which components are CRUs and
which components are FRUs.
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Error Code Type Error Message Action
0x80010900 Error Expansion Module 1 (BPE3 3.3V
Sense) voltage under critical
threshold. with chassis Reading:
X, Threshold: Y
1. If the under voltage problem is occurring on all
blade servers, look for other events in the log
related to power and resolve those events.
2. View the event log provided by the advanced
management module for your BladeCenter unit
and resolve any power related errors that might
be displayed.
3. If other modules or blades are logging the same
issue then check the power supply for the
BladeCenter unit.
4. If the error continues, replace the Blade PCI
Express I/O expansion unit. See “Removing an
optional expansion unit” on page 57 and
“Installing an optional expansion unit” on page
58.
0x80010900 Error System board (Planar 12V)
voltage over critical threshold.
Reading: X, Threshold: Y
1. If the over voltage problem is occurring on all
blade servers, look for other events in the log
related to power and resolve those events.
2. View the event log provided by the advanced
management module for your BladeCenter unit
and resolve any power related errors that might
be displayed.
3. If other modules or blades are logging the same
issue then check the power supply for the
BladeCenter unit.
4. If the error continues, replace the system-board
assembly (see “Removing the system-board
assembly” on page 94 and “Installing the
system-board assembly” on page 95).
0x80010900 Error System board (Planar 3.3V)
voltage over critical threshold.
Reading: X, Threshold: Y
Replace the blade (see “Removing the system-board
assembly” on page 94 and “Installing the
system-board assembly” on page 95).
0x80010900 Error System board (Planar 5V)
voltage over critical threshold.
Reading: X, Threshold: Y
1. Remove all expansion cards from the blade server
(see “Removing an I/O expansion card” on page
74).
2. Remove all storage drives from the blade server
(see “Removing a SSD storage drive” on page 61).
3. If the error continues, replace the system-board
assembly (see “Removing the system-board
assembly” on page 94 and “Installing the
system-board assembly” on page 95).
Chapter 6. Diagnostics 105
