Table 4. Enclosure weight as FRUs are installed (continued)
Enclosure assembly Approximate weight
FRUs installed FRUs not installed kg lb
• Enclosure
• Secondary expansion modules
• Fascia (1U and 4U)
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• Display assembly
• Drives
• Cover
44.3 97.7
• Enclosure
• Secondary expansion modules
• Fascia (1U and 4U)
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• Display assembly
• Drives
• Cover
58 127.9
Note: The following FRUs are
installed when the enclosure is
initially shipped.
• Enclosure
• Secondary expansion modules
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• Display assembly
• Cover
• Fascia (1U and 4U)
• Drives
61.5 135.4
• Enclosure
• Secondary expansion modules
• Fascia (1U and 4U)
• PSUs
• Expansion canisters
• Fan modules
• Fan interface boards
• Cover
78.6 173.3
Conversely, the overall weight of the expansion enclosure is reduced as you remove parts. However, even
with parts removed, the Model 092 expansion enclosure is heavy. Depending on the number of parts that
remain, you might need four persons or a mechanical lift to support the weight of the expansion
enclosure.
