Table 2. Weight of expansion enclosure parts (continued)
FRU description
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Fan interface board 0.118 0.260 1 0.236 0.260
Weight of expansion enclosure SAS drives
The SAS drives are shipped in a separate package from the Model 092 expansion enclosure. The
enclosure can support up to 92 SAS drives; however, the quantity varies depending on the number of
drives ordered.
Table 3. Weight of expansion enclosure drives
FRU description Approximate weight per unit
kg lb
800 GB 2.5-inch SSD 0.224 0.494
6 TB 3.5-inch HDD 0.876 1.931
10 TB 3.5-inch HDD 0.876 1.931
14 TB 3.5-inch HDD 0.876 1.931
16 TB 3.5-inch HDD 0.670 1.477
Weight increases as FRUs are installed
As you install or replace FRUs, the overall weight of the expansion enclosure increases. For example,
Table 4 on page 16 shows the weight progression as different combinations of FRUs are installed.
Table 4. Enclosure weight as FRUs are installed
Enclosure assembly Approximate weight
FRUs installed FRUs not installed kg lb
• Enclosure • Secondary expansion modules
• Fascia (1U and 4U)
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• Display assembly
• Drives
• Cover
42.5 93.7
16 IBM Elastic Storage System 5000: Model 092 Hardware Guide
