IBM Flex System x440 Compute Node User Manual

Before you install a microprocessor and heat sink, complete the following steps:
1. Read “Safety” on page v and “Installation guidelines” on page 487.
2. If the compute node is installed in an IBM Flex System chassis, remove it (see
“Removing a compute node from a chassis” on page 489 for instructions).
3. Carefully lay the compute node on a flat, static-protective surface, orienting the
compute node with the bezel pointing toward you.
About this task
The following notes describe the type of microprocessor that the compute node
supports and other information that you must consider when you install a
microprocessor:
4x CPU (Normal config)
Socket 3 Socket 1
Socket 4 Socket 2
CPU
1
ETE
Mezz 1
Mezz 2
Mezz 3
Mezz 4
DMI
SW
PCH
4x CPU
()CPU 2 functional but socket 1 DMI path broken
Socket 3 Socket 1
Socket 4 Socket 2
CPU
0
ETE
Mezz 1
Mezz 2
Mezz 3
Mezz 4
DMI
SW
PCH
CPU
0
CPU
1
CPU
3
CPU
2
CPU
3
CPU
2
Figure 4. Supported four CPUs configuration
546 IBM Flex System x440 Compute Node Types 7917 and 2584: Installation and Service Guide
