i. If the drive you want to replace is unprotected or in use, move the data from the drive before you
continue with this procedure. If the drive is in a RAID 0 (non-redundant RAID array), after you
move the data, delete the RAID 0 before proceeding. For SAS RAID controller information, see the
SAS RAID controllers for Linux(http://www.ibm.com/support/knowledgecenter/POWER8/
p8ebk/p8ebk_kickoff.htm).
j. Look for the drive at the SCSI location you recorded. The drive might have a Failed status.
k. Return to the IBM Power RAID Configuration Utility display.
l. If you are removing a solid-state device that is on a PCIe RAID and SSD SAS adapter, go to
Removing and replacing the SAS RAID adapter(http://www.ibm.com/support/knowledgecenter/
POWER8/p8ebj/p7ebjBDRemoveReplace.htm), and complete that procedure.
m. From the IBM Power RAID Configuration Utility display, select Work with disk unit recovery.
Press Enter.
n. From the Work with Disk Unit Recovery display, select Concurrent remove device, and press
Enter. A Concurrent Device Remove display is shown, similar to the following examples shown in
Figure 87 and Figure 88 on page 88.
Display Hardware Status
Type option, press Enter.
1=Display hardware resource information details
OPT Name Resource Path/Address Vendor Product ID Status
--- ------ -------------------------- -------- ---------------- ----------------
sg23 FE IBM 57CE001SISIOA Operational
sg0 00-0E-01 IBM SG9XCA2E200GEIBM Active
sg1 00-0E-0A IBM SG9XCA2E200GEIBM Active
sg2 00-0E-0B IBM SG9XCA2E200GEIBM Active
sg3 00-0E-03 IBM SG9XCA2E200GEIBM Active
sg4 00-0E-09 IBM SG9XCA2E200GEIBM Active
sg5 00-0E-02 IBM SG9XCA2E200GEIBM Failed
sg6 00-0E-04 IBM SG9XCA2E200GEIBM Active
sg7 00-0C-26 IBM 5887 Active
sg8 00-0E-26 IBM 5887 Active
sg47 FE IBM 57CE001SISIOA Operational
sg26 00-0E-01 IBM SG9XCA2E200GEIBM Remote
sg27 00-0E-0A IBM SG9XCA2E200GEIBM Remote
sg28 00-0E-0B IBM SG9XCA2E200GEIBM Remote
More...
e=Exit q=Cancel r=Refresh t=Toggle f=PageDn b=PageUp
Figure 86. Example Display Hardware Status
Concurrent Device Remove
Choose a single location for remove operations
1=Select
OPT Name PCI/SCSI Location Description Status
--- ------ -------------------------- ------------------------- -----------------
U5887.001.Z065075-P1-D1 Empty
sg0 U5887.001.Z065075-P1-D2 Advanced Function SSD Active
sg5 U5887.001.Z065075-P1-D3 Advanced Function SSD Failed
sg3 U5887.001.Z065075-P1-D4 Advanced Function SSD Active
sg6 U5887.001.Z065075-P1-D5 Advanced Function SSD Active
U5887.001.Z065075-P1-D6 Empty
U5887.001.Z065075-P1-D7 Empty
U5887.001.Z065075-P1-D8 Empty
U5887.001.Z065075-P1-D9 Empty
sg4 U5887.001.Z065075-P1-D10 Advanced Function SSD Active
sg1 U5887.001.Z065075-P1-D11 Advanced Function SSD Active
sg2 U5887.001.Z065075-P1-D12 Advanced Function SSD Active
Figure 87. Example Concurrent Device Remove display
Disk drives or solid-state drives 87
