Power supply
support bracket
Power supply
release tab
11. If you have a hot-swap model, reinstall the hot-swap power-supplies.
If
you have other options to install or remove, do so now; otherwise, go to
“Completing the installation” on page 31.
Installing a drive
Depending on the server model, the server might come with an integrated drive
electronics (IDE) CD-ROM, CD-RW, or DVD/CD-RW combo drive in bay 1.
The following are illustrations of the server and the location of the drive bays. Your
hardware might differ, depending on the model.
The following is an illustration of hot-swap server models.
Chapter 2. Installing options 21
