IBM System x3400 Type 7975 User Manual

Completing the installation
To complete the installation, you must replace the bezel, reinstall the side cover,
and connect all the cables and, for certain options, run the Configuration/Setup
Utility program. Follow the instructions in this section.
Replacing the bezel
To replace the bezel, complete the following steps:
1. Align the hinge assembly with the hinge holes on the chassis.
Bezel
Retention tabs
Hinge assembly
2. Push the hinges into the holes on the chassis until they snap into place.
3. If however, the bezel was removed by detaching the sliding hinge mount from
the hinge assembly (using the breakaway method as the bezel was designed to
do), complete the following steps to reattach the bezel:
a. Press in on the rear of the sliding hinge mount until it extends beyond the
edge of the bezel and hold it in place.
Chapter 2. Installing options 31

IBM System x3400 Type 7975 Specifications

General

Processor Sockets	2
Memory Slots	8 DIMM slots
Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 5000/5100/5300 series, Intel Core 2 Duo
Memory	Up to 32 GB DDR2 ECC
Form Factor	Tower
RAID Support	RAID 0, 1
Power Supply	835W (optional redundant)
Hard Drive Interface	SATA/SAS
