Sliding hinge mount
Hinge assembly Hinge pin
b. Align the sliding hinge mount with the hinge pin on the hinge assembly on
the chassis.
c. Press the sliding hinge mount against the hinge pin until the sliding hinge
mount snaps onto the hinge pin.
4. Close the bezel.
32 System x3400 Types 7973, 7974, 7975, and 7976: Installation Guide

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the IBM System x3400 Type 7975 and is the answer not in the manual?

IBM System x3400 Type 7975 Specifications

General IconGeneral
Processor Sockets2
Memory Slots8 DIMM slots
ChipsetIntel 5000P
NetworkDual Gigabit Ethernet
Operating System SupportMicrosoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
ProcessorIntel Xeon 5000/5100/5300 series, Intel Core 2 Duo
MemoryUp to 32 GB DDR2 ECC
Form FactorTower
RAID SupportRAID 0, 1
Power Supply835W (optional redundant)
Hard Drive InterfaceSATA/SAS
