ICM Controls i3 2010WR User Manual

14
7.HeatSource:Therearesixheatsourcesettings:
WARNING! : Incorrectsettingscandamagesystemand/orcausepotentiallydangerousconditions.Usethecode
describedinCongurationandThermostatLock.
Non-HeatPump
CONFIG
Electric
CONFIG
Gas
HeatPump
CONFIG
HeatPumpwith
2compressors
andHeatActive
ReversingValve
CONFIG
HeatPumpwith
2compressors
andCoolActive
ReversingValve
CONFIG
HeatPumpwith
1compressor
andHeatActive
ReversingValve
CONFIG
HeatPumpwith
1compressor
andCoolActive
ReversingValve
6.MinimumDeadband(1°Fto9°F)(1°Cto5°C)
SettheminimumseparationbetweenheatsetpointandcoolsetpointinAutoChangeoverMode.
Pressthe
or tosetdeadbandvalue.
Press
toadvancetothenextscreen.
CONFIG
5.StagedOffOutputs
Selectwhethertheoutputsforheatingandcoolingarestagedoffindependentlyorare
satisedsimultaneously.

=Outputsoffsimultaneously(bestfordualfuel). =Outputsstagedoffindependently.
Note: For 2 compressor heat pumps and multi-stage gas/oil systems, stage 3 is staged off
independently when SO is set to
.
Pressthe
or toset.
Press
toadvancetothenextscreen.
CONFIG
